Spherical roller bearing 22206C 30*62*20mm High Mechanical Efficiency For Mining Machinery
22206C Spherical Roller Bearing:
30*62*20mm Bearing Features:
Inner Ring Diameter (bore): 30mm
Outer Ring Diameter:62mm
Width:20mm
Basic Dynamic Load Rating Cr:51.7kN
Basic Static Load Rating Cor:55kN
Grease:6800
Oil:9100
Bearings Weight:0.294KG
22206C Spherical Roller Bearing Description:
| Model Number: | 22206C |
| Inner diameter: | 30mm |
| Outer diameter: | 62mm |
| Width: | 20m |
| Bearing Weight: | 0.294KG |
| Seal Type: | Double Shielded, 2RS |
| Material: | Chrome steel, Gcr15 |
| Precision Rating: | P0-P5 |
| Brand: | TOPE or other brands |
| Payment term: | T/T,L/C,Western Union, PayPal |
| Delivery time: | 1-5 days for small amout, 15-40 days for big amount
|
22206C Spherical Roller Bearing:
more models:
| Bearing No. | | Rated Load | | Weight |
| (mm) | (kN) | (r/min) | (kg) |
| New | Old | d | D | B | Cr | Cor | Grease | Oil | wt |
| 22205CA | 53505H | 25 | 52 | 18 | 42.1 | 43.5 | 8100 | 11000 | 0.186 |
| 22205CTN1 | | 25 | 52 | 18 | 42.1 | 43.5 | 8100 | 11000 | 0.186 |
| 22205M | | 25 | 52 | 18 | 43 | 42.1 | 8100 | 11000 | 0.179 |
| 22206CA | 53506H | 30 | 62 | 20 | 51.7 | 55 | 6800 | 9100 | 0.294 |
| 22206C | 53506 | 30 | 62 | 20 | 51.7 | 55 | 6800 | 9100 | 0.294 |
| 22206MB | | 30 | 62 | 20 | 51.7 | 55 | 6800 | 9100 | 0.294 |
| 22206M | | 30 | 62 | 20 | 55.2 | 56.8 | 6800 | 9100 | 0.286 |
| 22207CA | 53507H | 35 | 72 | 23 | 67 | 73.9 | 5900 | 7800 | 0.447 |
| 22207C | 53507 | 35 | 72 | 23 | 67 | 73.9 | 5900 | 7800 | 0.447 |
| 22207MB | | 35 | 72 | 23 | 67 | 73.9 | 5900 | 7800 | 0.447 |
| 22207M | | 35 | 72 | 23 | 74.1 | 82.2 | 5900 | 7800 | 0.437 |
| 22208CA | 53508H | 40 | 80 | 23 | 76.9 | 85 | 5200 | 6900 | 0.536 |
| 22208C | 53508 | 40 | 80 | 23 | 76.9 | 85 | 5200 | 6900 | 0.536 |
| 22208MB | | 40 | 80 | 23 | 76.9 | 85 | 5200 | 6900 | 0.536 |
| 22208M | | 40 | 80 | 23 | 85.4 | 93.4 | 5200 | 6900 | 0.525 |
| 22308CA | 53608H | 40 | 90 | 33 | 115 | 127 | 4000 | 5300 | 1.03 |
| 22308C | 53608 | 40 | 90 | 33 | 115 | 127 | 4000 | 5300 | 1.03 |
| 22308MB | | 40 | 90 | 33 | 115 | 127 | 4000 | 5300 | 1.03 |
| 22308M | | 40 | 90 | 33 | 132 | 147 | 4000 | 5300 | 1.02 |
| 22209CA | 53509H | 45 | 85 | 23 | 80.5 | 91.9 | 4900 | 6500 | 0.597 |
| 22209C | 53509 | 45 | 85 | 23 | 80.5 | 91.9 | 4900 | 6500 | 0.597 |
| 22209MB | | 45 | 85 | 23 | 80.5 | 91.9 | 4900 | 6500 | 0.597 |
| 22209M | | 45 | 85 | 23 | 89.6 | 101 | 4900 | 6500 | 0.585 |
| 22309CA | 53609H | 45 | 100 | 36 | 146 | 168 | 3600 | 4800 | 1.43 |
| 22309C | 53609 | 45 | 100 | 36 | 146 | 168 | 3600 | 4800 | 1.43 |
| 22309MB | | 45 | 100 | 36 | 146 | 168 | 3600 | 4800 | 1.43 |
| 22309M | | 45 | 100 | 36 | 162 | 182 | 3600 | 4800 | 1.42 |
| 22210CA | 53510H | 50 | 90 | 23 | 83.1 | 97.8 | 4500 | 6000 | 0.641 |
| 22210C | 53510 | 50 | 90 | 23 | 83.1 | 97.8 | 4500 | 6000 | 0.641 |
| 22210MB | | 50 | 90 | 23 | 83.1 | 97.8 | 4500 | 6000 | 0.641 |
| 22210M | | 50 | 90 | 23 | 96.5 | 112 | 4500 | 6000 | 0.629 |
| 22310CA | 53610H | 50 | 110 | 40 | 181 | 208 | 3200 | 4300 | 1.87 |
| 22310C | 53610 | 50 | 110 | 40 | 181 | 208 | 3200 | 4300 | 1.87 |
| 22310MB | | 50 | 110 | 40 | 181 | 208 | 3200 | 4300 | 1.87 |
| 22310M | | 50 | 110 | 40 | 197 | 226 | 3200 | 4300 | 1.85 |
| 22211CA | 53511H | 55 | 100 | 25 | 102 | 119 | 4100 | 5400 | 0.849 |
| 22211C | 53511 | 55 | 100 | 25 | 102 | 119 | 4100 | 5400 | 0.849 |
22206C Spherical Roller Bearing Description:
1. The self-aligning roller bearing is a bearing with drum roller assembled between the inner ring with two raceways and the outer ring with spherical raceway.
2. The curvature center of raceway surface of outer ring is the same as that of bearing, so it has the same aligning function as automatic aligning ball bearing.
22206C Spherical Roller Bearing Features:
1. It has high radial load capacity and is especially suitable for working under heavy load or vibration load.
2. The raceway of bearing outer ring is spherical, so its alignment performance is good and it can compensate coaxiality error.
3. Bearing has a large load capacity. In addition to the radial load, the bearing can also bear the axial load of bidirectional action and has a good impact resistance.
Packing Method:
We have multiple packages for shielded radial ball bearing 22206C
1. Industrial package: plastic tube + paper carton + wooden pallet
craft paper + paper carton + wooden pallet
2. Individual package: individual paper box + paper carton + wooden pallet
3. As customer's demand
Factory Photo:
How to Place an Order:
1. Send us your bearing inquiry, including your bearing models, your quantity. If you have brand requirement, please tell us which brand do you need as well.
2. We will quote bearing price for you. Moreover, According to the quantity of goods, we will give you different options of transportation.
3. If you agree with our price, we will make proforma invoice for payment
4. After payment is done, we will start to prepare bearings and arrange shipment
Specific classification and model comparison:
1. Self-aligning roller bearing (20000CC type)
2. Tapered Hole Self-aligning Roller Bearing (Model 20000 CCK)
3. Self-aligning roller bearing (20000CC/W33)
4. Tapered bore self-aligning roller bearing (20000 CCK/W33)
5. Hole-aligning roller bearings (20000 CCK+H0000) mounted on the fastening sleeve
6. Hole-aligning roller bearings mounted on the fastening sleeve (20000 CCK/W33+H0000 type)
